D-Link DWL-2200AP [57/192] Navigating to wireless settings

Setting the Wireless Interface

Navigating to Wireless Settings

To set the wireless address for an access point, navigate to the Advanced > Wireless

tab, and update the fields as described below.

The following figure shows the Wireless settings page for a two-radio AP. The

Administration Web page for the single-radio AP will look slightly different.
