140
1. Configure the following settings on the Association tab on the Network Properties
dialog.
Appendix A: Configuring Security Settings on Wireless Clients
4. Click Configure to bring up the EAP MSCHAP v2 Properties dialog.
On this dialog, disable (click to uncheck) the option to “Automatically use my
Windows login name . . . “ etc.
Click OK on all dialogs (starting with the EAP MSCHAP v2 Properties dialog) to close
and save your changes.
Logging on to the Wireless Network with an IEEE 802.1x PEAP Client
IEEE 802.1x PEAP clients should now be able to associate with the access point.
Client users will be prompted for a user name and password to authenticate with the
network.
2. Configure this setting on the Authentication tab.
3. Click Properties to bring up the Protected EAP Properties dialog and configure the
following settings.
Protected EAP Properties Dialog
Validate Server Certificate Disable this option (click to uncheck the box).
Note: This example assumes you are using the Built-in
Authentication server on the AP. If you are setting up
EAP/PEAP on a client of an AP that is using an external
RADIUS server, you might certificate validation and
choose a certificate, depending on your infrastructure.
Select Authentication Method Choose “Secured password (EAP-MSCHAP v2)”.
Authentication Tab
EAP Type Choose “Protected EAP (PEAP)”.
Association Tab
Network Authentication Open
Data Encryption WEP
Note: An RC4 stream cipher is used to encrypt the
frame body and cyclic redundancy checking (CRC) of
each IEEE 802.11 frame. this is the same encryption
algorithm as is used for Static WEP; therefore, the
data encryption method configured on the client for
this mode is WEP.
This key is provided for me
automatically Enable (click to check) this option
