126
Maintenance and Monitoring
Verifying the Firmware Upgrade
To verify that the firmware upgrade completed successfully, check the firmware
version shown on the Advanced > Upgrade tab (and also on the Basic Settings tab). If
the upgrade was successful, the updated version name or number will be indicated.
Update
Click Update to apply the new firmware image.
Upon clicking Update for the firmware upgrade, a popup confirmation window is displayed
that describes the upgrade process.
Click OK to confirm the upgrade, and start the process.
The firmware upgrade file supplied must be in the format <FileName>.upgrade.tar.
Do not attempt to use <FileName>.bin files or files of other formats for the upgrade;
these will not work.
The firmware upgrade process begins once you click Update and then
OK in the popup confirmation window.
The upgrade process may take several minutes during which time the
access point will be unavailable. Do not power down the access point
while the upgrade is in process. When the upgrade is complete, the access point
will restart and resume normal operation using the factory default configuration
settings.
