D-Link DWL-2200AP [142/192] Then configure ieee 802 x security with certificate authentication on each client as follows

142

Appendix A: Configuring Security Settings on Wireless Clients

If you configured the D-Link DWL-2210AP to use IEEE 802.1x security mode with an

external RADIUS server . . .

. . . then configure IEEE 802.1x security with certificate authentication on each client

as follows.

Choose WEP

Data Encryption

mode

Choose Open

Enable auto

key option

Choose Smart Card/Certificate

. . . then, click “Properties”

Enable (click to check) IEEE

802.1x authentication
