13
Administrator’s Computer
Configuration and administration of the D-Link DWL-2210AP is accomplished with the
KickStart utility (which you run from the CD) and through a Web-based user interface.
The DWL-2210AP must be installed into a DHCP-enabled network in order to
use the KickStart utility for configuration. The following table describes the
minimum requirements for the administrator’s computer.
Prelaunch Checklist
Required Software
or Component
Description
Ethernet Connection to
the First Access Point
The computer used to configure the first access point with
KickStart must be connected to the access point (either
directly or through a hub) by an Ethernet cable.
For more information on this step, see “Step 2. Connect the
access point to network and power” in Quick Steps for
Setup and Launch of Your Wireless Network.
After initial configuration and launch of the first access
points on your new wireless network, you can make
subsequent configuration changes through the
Administration Web pages using a wireless connection to
the “Internal” network. For wireless connection to the
access point, your administration device will need Wi-Fi
capability similar to that of any wireless client:
• Portable or built-in Wi-Fi client adapter that supports one
or more of the IEEE 802.11 modes in which you plan to run
the access point. (IEEE 802.11b, 802.11g, and 802.11g
Turbo modes are supported.)
• Wireless client software such as Microsoft Windows XP
or Funk Odyssey wireless client configured to associate
with the D-Link DWL-2210AP.
For more details on Wi-Fi client setup, see “Wireless Client
Computers” in this manual.
Wireless Connection
to the Network
