11
Option Default Settings Related Information
Default Settings (continued):
Connection Type
Dynamic Host Configuration
Protocol (DHCP)
If you do not have a DHCP server on
the Internal network and do not plan
to use one, the first thing you must
do after bringing up the access point
is to change the Connection Type
from “DHCP” to “Static IP.” The Guest
network must have a DHCP server.
Subnet Mask None
This is determined by your network
setup and DHCP server configuration.
Radio On “Configuring Radio Settings”
IEEE 802.11 Mode 802.11g “Configuring Radio Settings”
802.11g Channel Auto “Configuring Radio Settings”
Beacon Interval 100 “Configuring Radio Settings”
DTIM Period 2 “Configuring Radio Settings”
2346 “Configuring Radio Settings”
Fragmentation
Threshold
RTS Threshold 2347 “Configuring Radio Settings”
MAX Stations 2007 “Configuring Radio Settings”
Transmit Power 100 percent “Configuring Radio Settings”
Rate Sets
Supported (Mbps)
“Configuring Radio Settings”
• IEEE 802.1g: 54, 48, 36, 24, 18,
12, 11, 9, 6, 5.5, 2, 1
• IEEE 802.1b: 11, 5.5, 2, 1
