14
Administrator’s Computer (continued)
Required Software
or Component
Description
KickStart Wizard on
CD-ROM
CD-ROM Drive
The administrator’s computer must have a CD-ROM drive
to run the KickStart Wizard on the CD-ROM.
Security Settings
Ensure that security is disabled on the wireless client
used to initially configure the access point.
Web Browser / Operating
System
Configuration and administration of the D-Link
DWL-2210AP is provided through a Web-based user
interface hosted on the access point. We recommend
using one of the following supported Web browsers to
access the access point Administration Web pages:
• Microsoft Internet Explorer version 5.5 or 6.x (with
up-to-date patch level for either major version) on
Microsoft Windows XP or Microsoft Windows 2000
• Netscape Mozilla on Redhat Linux version 2.4
The administration Web browser must have JavaScript
enabled to support the interactive features of the
administration interface. It must also support HTTP
uploads to use the firmware upgrade feature.
Prelaunch Checklist
You can run the KickStart Wizard on the D-Link CD-ROM
on any Windows laptop or computer that is connected to
the access point either directly or through a switch. It
detects D-Link DWL-2210APs on the network. When used
in a DHCP-enabled network, the wizard steps you through
initial configuration of new access points, and provides a
link to the Administration Web pages where you finish up
the basic setup process in a step-by-step mode and
launch the network.
For more about using the KickStart Wizard, see “Step 3.
Run KickStart Wizard to find access points on the network”
in “Quick Steps for Setup and Launch of Your Wireless
Network” in this manual.
