15
Wireless Client Computers
The D-Link DWL-2210AP provides wireless access to any client with a properly configured
Wi-Fi client adapter for the 802.11b and 802.11g modes in which the access point is
running.
Multiple client operating systems are supported. Clients can be laptops or desktops,
personal digital assistants (PDAs), or any other hand-held, portable or stationary device
equipped with a Wi-Fi adapter and supporting drivers.
In order to connect to the access point, wireless clients need the following software
and hardware.
Required Software
or Component
Description
Wi-Fi Client Adapter
Portable or built-in Wi-Fi client adapter that supports one or
more of the IEEE 802.11 modes in which you plan to run the
access point. (IEEE 802.11b and 802.11g modes are
supported.)
Wi-Fi client adapters vary considerably. The adapter can be a
PC card built in to the client device, a portable PCMCIA or PCI
card (types of NICs), or an external device such as a USB or
Ethernet adapter that you connect to the client by means of a
cable.
The access point supports 802.11b/g modes, but you will
probably make a decision during network design phase as to
which mode to use. The fundamental requirement for clients
is that they all have configured adapters that match the
802.11 mode for which your access point(s) is configured.
Client software such as Microsoft Windows Supplicant or Funk
Odyssey wireless client configured to associate with the
D-Link DWL-2210AP.
Wireless Client Software
Prelaunch Checklist
