105
Configuring the Wireless Distribution System
(WDS)
The D-Link DWL-2210AP lets you connect multiple access points using a Wireless
Distribution System (WDS). WDS allows access points to communicate with one another
wirelessly in a standardized way. This capability is critical in providing a seamless
experience for roaming clients and for managing multiple wireless networks. It can also
simplify the network infrastructure by reducing the amount of cabling required.
The following sections describe how to configure the WDS on the D-Link DWL-2210AP:
• Understanding the Wireless Distribution System
• Using WDS to Bridge Distant Wired LANs
• Using WDS to Extend the Network Beyond the Wired Coverage Area
• Backup Links and Unwanted Loops in WDS Bridges
• Security Considerations Related to WDS Bridges
• Navigating to WDS Settings
• Configuring WDS Settings
• Example of Configuring a WDS Link
• Updating Settings
Understanding the Wireless Distribution System
A Wireless Distribution System (WDS) is an 802.11f technology that wirelessly connects
access points, known as Basic Service Sets (BSS), to form what is known as an Extended
Service Set (ESS).
A BSS generally equates to an access point (deployed as a single-AP wireless
“network”), except in cases where multi-BSSID features make a single access
point look like two or more access points to the network. In such cases, the access
point has multiple unique BSSIDs
