D-Link DWL-2200AP [137/192] Connecting to the wireless network with a static wep client

137

Appendix A: Configuring Security Settings on Wireless Clients

Click OK on the Wireless Network Properties dialog to close it and save your changes.

Connecting to the Wireless Network with a Static WEP Client

Static WEP clients should now be able to associate and authenticate with the access

point. As a client, you will not be prompted for a WEP key. The WEP key configured on

the client security settings is automatically used when you connect.

Authentication Tab

Make sure that IEEE 802.1x authentication is disabled (box should

be unchecked).

(Setting the encryption mode to WEP should automatically disable

authentication.)

Enable IEEE 802.1x

authentication

for this network
