![D-Link DWL-2200AP [63/192] Enabling or disabling a network time protocol ntp server](/img/pdf.png)
D-Link DWL-2200AP [63/192] Enabling or disabling a network time protocol ntp server
![D-Link DWL-2200AP [63/192] Enabling or disabling a network time protocol ntp server](/views2/1044822/page63/bg3f.png)
63
To configure your access point to use a network time protocol (NTP) server, first enable
the use of NTP, and then select the NTP server you want to use. (To shut down NTP
service on the network, disable NTP on the access point.)
Field Description
Updating Settings
To apply your changes, click Update.
Network Time Protocol NTP provides a way for the access point to obtain and maintain its
time from a server on the network. Using an NTP server gives your
AP the ability to provide the correct time of day in log messages
and session information.
(See http://www.ntp.org
for more general information on NTP.)
Choose to either enable or disable use of a network time protocol
(NTP) server:
• Enabled
• Disabled
NTP Server If NTP is enabled, select the NTP server you want to use.
You can specify the NTP server by host name or IP address,
although using the IP address is not recommended as these can
change more readily.
Field Description
Enabling or Disabling a Network Time Protocol (NTP) Server
Enabling the Network Time Protocol Server
