55
Configuring Guest Interface Ethernet Settings
To configure Ethernet settings for the “Guest” interface, fill in the fields as described
below.
Field Description
MAC Address
VLAN ID
Field Description
Subnet Mask Enter the Subnet Mask in the text boxes. You must obtain this
information from your ISP or network administrator.
Default Gateway Enter the Default Gateway in the text boxes.
Static IP Address If you chose “Static IP” as the Connection Type, these fields will be
enabled.
Enter the Static IP Address in the text boxes.
Updating Settings
To apply your changes, click Update.
DNS Nameservers
Field Description
The Domain Name Service (DNS) is a system that resolves the
descriptive name (domain name) of a network resource (for
example, www.dlink.com) to its numeric IP address (for
example, 66.93.138.219). A DNS server is called a Nameserver.
There are usually two Nameservers; a Primary Nameserver and
a Secondary Nameserver.
You can choose Dynamic or Manual mode.
• If you choose Manual, you should assign static IP addresses
manually.
• If you choose Dynamic, the IP addresses for the DNS servers
will be assigned automatically via DHCP. (This option is only
available if you specified DHCP for the Connection Type.)
Field Description
Shows the MAC address for the Guest interface for the Ethernet
port on this access point. This is a read-only field that you
cannot change.
If you enable Guest access and configure Internal and Guest
networks by “VLANs”, this field will be enabled.
Provide a number between 1 and 4094 for the Guest VLAN.
Setting the Ethernet (Wired) Interface
