Appendix B: Troubleshooting

At this point you should see all previous cluster members displayed in the list.

Before proceeding to the last step, verify that the cluster has reformed by making sure

all are access points are listed.

4. Review all configuration settings and make modifications as needed.

Pay special attention to the security settings because after a reset, Access Points

run without any security in place.
