See Also
For information on how to configure WPA with RADIUS security mode, see “WPA with
RADIUS” under “Configuring Security Settings” in this manual.
When to Use WPA-PSK
Wi-Fi Protected Access (WPA) with Pre-Shared Key (PSK) is a Wi-Fi Alliance subset of
IEEE 802.11i, which includes Temporal Key Integrity Protocol (TKIP) Advanced Encryption
Algorithm (AES), and Counter mode/CBC-MAC Protocol (CCMP) mechanisms. This
mode offers the same encryption algorithms as WPA with RADIUS but without the ability
to integrate a RADIUS server for user authentication.
K
WPA-PSK provides
dynamically-generated
keys that are periodically
refreshed.
There are different
Unicast keys for
each station.
• Temporal Key Integrity
Protocol (TKIP)
• Counter mode/CBC-MAC
Protocol (CCMP) Advanced
Encryption Standard (AES)
The use of a Pre-Shared
(PSK) key provides user
authentication similar
to that of shared keys in WEP.
Key Management Encryption Algorithm User Authentication
If there are older client stations on your network that do not support WPA, you can
configure WPA with RADIUS (with Both, CCMP, or TKIP) and check the “Allow non-WPA
IEEE 802.1x clients” checkbox to allow non-WPA clients. This way, you get the benefit
of IEEE 802.1x key management for non-WPA clients along with even better data
protection of TKIP and CCMP (AES) key management and encryption algorithms for
your WPA clients.
A typical scenario is that one is upgrading a current 802.1x network to use WPA. You
might have a mix of clients; some new clients that support WPA and some older ones
that do not support WPA. You might even have other access points on the network that
support only 802.1x and some that support WPA with RADIUS. For as long as this mix
persists, use the “Allow non-WPA IEEE 802.1x clients” option.
When all the stations have been upgraded to use WPA, you should disable the “Allow
non-WPA IEEE 802.1x clients” option.
