DNS-6040M/DNS-6040 User’s Manual
54
Note that all users must belong either to the users or the
guests group. If the system administrator uses this page to move
a member from the guests group to the users group, the account
will automatically be removed from the guests group, and vice
versa. However, accounts belonging to guests or users group
can be assigned to other groups, including the predefined
admins group, or any other group set up by the administrator.
Deleting group members
To remove a member from a group, select the name from
the list of members (use Ctrl for multiple and Shift for
continuous selection), then click Remove.
TIP
If a user is connected to the server while the administrator is modifying the
user’s security settings, these changes will not be activated immediately, but
only after the user logs out and back in again.
User Quota Setup
There are two ways a system administrator can view and
modify quota setup in the NAS server, by user or by volume.
