Chapter8 Reliability Configuration

8-39

Send interval: 2000

Peer exist: EXIST

Peer mac: 0:4:67:97:db:83

Peer role: SLAVE

Peer state: BLOCK

Peer Reverse: disable

Peer send interval: 2000

Peer linkstate: up

Member

Role

State Sendvid

Status

ge-1/1

MASTER

FORWARD 0

ACTIVE

ge-1/2

SENDER

FORWARD 0

ACTIVE

8.3.6.3 Configure MLINK

Network Requirements

Configure MLINK on Switch, fe1/1 is uplink1, fe1/2 is uplink2, fe1/3 is downlink1, fe1/4

is downlink2.

Network Diagram
