Chapter2 Layer 2 Ethernet Configuration
2-48
SwitchA(config)#
//Create carrier operator network VLAN100 and VLAN101.
SwitchA(config)#interface vlan 100
SwitchA(config-vlan-100)#quit
SwitchA(config)#interface vlan 101
SwitchA(config-vlan-101)#quit
SwitchA(config)#
//Create VLAN translation rule table: VLAN10->VLAN100, VLAN11->VLAN101 and
VLAN12->VLAN101.
SwitchA(config)#
SwitchA(config)# translation-vlan 1 outer-vlan 10 replace outer 100
SwitchA(config)# translation-vlan 2 outer-vlan 11 replace outer 101
SwitchA(config)# translation-vlan 3 outer-vlan 12 replace outer 101
//Enter the GE1/0/1 and add interface into VLAN10, VLAN 11, VLAN100 and
VLAN101.
SwitchA(config)#interface fastethernet 1/0/1
SwitchA(config-ge1/0/1)#port hybrid vlan 10 tagged
SwitchA(config-ge1/0/1)#port hybrid vlan 11 tagged
SwitchA(config-ge1/0/1)#port hybrid vlan 100 untagged
SwitchA(config-ge1/0/1)#port hybrid vlan 101 untagged
//Bind VLAN translation item to interface.
SwitchA(config-ge1/0/1)#join translation-vlan 1 in
SwitchA(config-ge1/0/1)#join translation-vlan 2 in
SwitchA(config-ge1/0/1)#quit
//Enter the GE1/0/2 and add interface into VLAN12 and VLAN101.
SwitchA(config)#interface fastethernet 1/0/2
SwitchA(config-ge1/0/2)#port hybrid vlan 12 tagged
SwitchA(config-ge1/0/2)#port hybrid vlan 101 untagged
SwitchA(config-ge1/0/2)# join translation-vlan 3 in
SwitchA(config-ge1/0/2)#quit
SwitchA(config)#
//Create VLAN translation rule table: VLAN101->VLAN10, VLAN101->VLAN11 and
VLAN101->VLAN12.
SwitchA(config)#
SwitchA(config)# translation-vlan 1 outer-vlan 100 replace outer 10
SwitchA(config)# translation-vlan 2 outer-vlan 101 replace outer 11
