Chapter2 Layer 2 Ethernet Configuration
2-49
SwitchA(config)#translation-vlan 3 outer-vlan 101 replace outer 12
//Enter the GE1/0/3 and add interface into VLAN10, VLAN 11, VLAN12, VLAN100 and
VLAN101.
SwitchA(config)#interface fastethernet 1/0/3
SwitchA(config-ge1/0/3)#port trunk allow-pass vlan 10 untagged
SwitchA(config-ge1/0/3)#port trunk allow-pass vlan 11 untagged
SwitchA(config-ge1/0/3)#port trunk allow-pass vlan 12 untagged
SwitchA(config-ge1/0/3)#port trunk allow-pass vlan 100 tagged
SwitchA(config-ge1/0/3)#port trunk allow-pass vlan 101 tagged
//Bind VLAN translation item to interface.
SwitchA(config-ge1/0/3)#join translation-vlan 1 in
SwitchA(config-ge1/0/3)#join translation-vlan 2 in
SwitchA(config-ge1/0/3)#join translation-vlan 3 in
SwitchA(config-ge1/0/3)#
SwitchA(config-ge1/0/3)#quit
