- 7 -
Item Code Description
1 R_USB3 USB 3.0 Port
2 LAN1_2 GbE Ethernet LAN Port #1/GbE Ethernet LAN Port #2
3 USB3_MLAN Server Management LAN Port (Top)/ USB3.0 Ports (Bottom)
4 SW_ID ID button with LED
5 MEZZ_1A/MEZZ_1B OCP Mezzanine Connector
6 COM1_VGA Serial Port (Top)/ VGA Port (Bottom)
7 SYS_FAN1 System Fan Connector #1
8 SYS_FAN2 System Fan Connector #2
9 BAT1 Battery Socket
10 ATX1 2 x 12 Pin Main Power Connector
11 CPU0_FAN CPU Fan Connector #0
12 P12V_AUX1 2 x 4 Pin Power Connector (for CPU)
13 P12V_AUX2 2 x 4 Pin Power Connector (for Memory)
14 SATA0 Slimline SAS 4i Connector (SATAIII 6Gb/s Signal)
15 SATA1 Slimline SAS 4i Connector (SATAIII 6Gb/s Signal)
16 U2_3 Slimline SAS 4i Connector (NVMe/PCIe Gen3 x4)
17 U2_1 Slimline SAS 4i Connector (NVMe/PCIe Gen3 x4)
18 U2_0 Slimline SAS 4i Connector (NVMe/PCIe Gen3 x4)
19 U2_2 Slimline SAS 4i Connector (NVMe/PCIe Gen3 x4)
20 F_USB3 Front Panel USB 3.0 Connector
21 FP_1 Front Panel Header
22 BP_1 HDD Back Plane Board Connector
23 M2_1 M.2 slot (PCIe Gen3 x4, Support NGFF-2242/2260/2280)
24 M2_2 M.2 slot (PCIe Gen3 x4, Support NGFF-2242/2260/2280)
25 CASE_OPEN Case Open Intrusion Alert Header
26 SYS_FAN5 System Fan Connector #5
27 F_USB2 USB 2.0 Header
28 SPI_TPM TPM Module Connector
29 SYS_FAN4 System Fan Connector #4
30 SYS_FAN3 System Fan Connector #3
31 COM2 Serial Port Cable Connector
32 PCIE_1 PCIe x16 Slot (Gen3 x16/x8)
33 PCIE_2 PCIe x8 Slot (Gen3 x0/x8)
34 PCIE_3 PCIe x16 Slot (Gen4 x16)
35 PCIE_4 PCIe x16 Slot (Gen4 x16)
36 PCIE_5 PCIe x16 Slot (Gen4 x8)
37 PCIE_6 PCIe x16 Slot (Gen4 x16)
38 PCIE_7 PCIe x16 Slot (Gen4 x16) switch with 4 x Slim-SAS 4i from 4 x U.2
39 SLINK3 Slimline SAS 4i Connector
40 SLINK2 Slimline SAS 4i Connector
41 SLINK1 Slimline SAS 4i Connector
42 SLINK0 Slimline SAS 4i Connector
43 IPMB IPMB Connector
44 LED_BMC BMC Firmware Readiness LED
