- 13 - Hardware Installation
Internal
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connector
2 x Mini-SAS HD connectors
10 x SATA3 6Gb/s connectors
1 x PMBus header
2 x CPU fan headers
5 x System fan headers
1 x Front panel header
1 x HDD Back plane board header
1 x USB 3.0 header
1 x USB 2.0 header
1 x TPM module connector
1 x Serial port connector
1 x SATA SPGIO header
1 x sSATA SPGIO header
1 x IPMB connector
1 x Software RAID key connector
1 x LSI RAID key connector
1 x S/PDIF in header
1 x S/PDIF out header
2 x LAN LED connectors
1 x Chassis intrusion alert header
Rear Panel I/O 2 x USB 3.0 ports
2 x USB 2.0 ports
2 x RJ-45 ports
1 x COM port
5 x Audio connectors (Center/Subwoofer Speaker Out, Rear Speaker Out, Line
In/Mic In, Line Out, Headphone)
1 x Optical SPDIF Out
I/O Controller ASPEED
®
AST2400-VB chip
Hardware
Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
BIOS 1x128Mbitash
AMI BIOS
Form Factor EATX Form Factor; 13 inch x 12 inch
*GIGABYTEreservestherighttomakeanychangestotheproductspecicationsandproduct-relatedinformationwithout
prior notice.
