Hardware Installation - 12 -
1-2 Product Specications
CPU Support for Intel
®
Xeon
®
E5-2600 V3/V4 series processors in the LGA2011
package
L3 cache varies with CPU
Supports Dual QuickPath Interconnect up to 9.6GT/s
Enhanced Intel
®
SpeedStep Technology (EIST)
Support Intel
®
Virtualization Technology (VT)
Chipset Intel
®
C612 Express (Wellsburg) Chipset
Memory 16 x DIMM slots
DDR4 memory supported only
Quad channel memory architecture
ECC RDIMM / LRDIMM modules supported
Single and dual rank RDIMM modules up to 32GB supported
3DS LRDIMM modules up to 128GB supported
1.2V modules: 1600/1866/2133/2400 MHz
LAN 2 x Intel
®
I210 supports supports dual GbE LAN ports
Expansion Slots 1 x PCI Express x16 slot, running at x16 (Gen3/PCIE_6)
1 x PCI Express x16 slot, running at x16 (Gen3/PCIE_4/The slot shares bandwidth
with the PCIE_5 slot. When PCIE_5 slot is populated, the PCIE_4 will operate
at x8 mode.)
1 x PCI Express x16 slot, running at x16 (Gen3/PCIE_2/The slot shares bandwidth
with the PCIE_3 slot. When PCIE_3 slot is populated, the PCIE_2 will operate
at x8 mode.)
3 x PCI Express x8 slots (GEN3/PCIE_1/PCIE_3/PCIE_5)
Audio RealtekALC887codecHighDenitionAudio
7.1 Channel
Onboard
Graphics
ASPEED
®
AST2400 supports 128MB DDR3 VRAM
Storage Interface 10 x SATA3 6Gb/s connectors
2 x Mini-SAS HD connectors
Support for Intel
®
RSTe 4.0 with RAID 0, 1, 10, 5
LSI
®
3008 controller supports LSI RAID 0, 1, 1E, 10
USB Up to 4 USB 3.0 ports (2 on the back panel, 2 additional ports via the USB
brackets connected to the internal USB headers)
Up to 4 USB 2.0 ports (2 on the back panel, 2 additional ports via the USB
brackets connected to the internal USB headers)
