Gigabyte MW70-3S0 (rev. 1.0) [42/135] Bmc_frb force to stop frb timer jumper

Hardware Installation - 42 -

6) BMC_FRB (Force to Stop FRB Timer Jumper)

1-2 Close: Normal operation. (Default setting)

2-3 Close: Force to Stop FRB Timer.

BMC_FRB

7) ME_RCVR (ME Recovery Jumper)

1-2 Close: Normal operation. (Default setting)

2-3 Close: ME recovery mode.

ME_RCVR
