Gigabyte MW70-3S0 (rev. 1.0) [74/135] 2 14 iscsi configuration

BIOS Setup - 74 -

2-2-14 iSCSI Conguration

iSCSI Initiator Name

Add an Attempts

 Press[Enter]forcongurationofadvanceditems.

Delete Attempts

 Press[Enter]forcongurationofadvanceditems.

Change Attempt Order

 Press[Enter]forcongurationofadvanceditems.
