Gigabyte MW70-3S0 (rev. 1.0) [38/135] Led5 lsi firmware readiness led

Hardware Installation - 38 -

37) LED5 (LSI Firmware Readiness LED)

State Description

On LSIrmwareisinitial

Blinking LSIrmwareisready

Off AC loss
