Gigabyte MW70-3S0 (rev. 1.0) [37/135] Imr_key lsi raid key header

- 37 - Hardware Installation

Open: Normal operation.

Closed: Active chassis intrustion alert.

36) CASE_OPEN (Case open intrusion alert header)

35) IMR_KEY (LSI RAID Key Header)

PinNo. Denition

1 KEY

2 GND
