Icom IC-R9500 [120/194] Scan delay

8-18

SCANS

■ Scan speed

➥ Rotate [SPEED] to adjust the scan speed.

[SPEED]

■ Scan delay

➥ Rotate [DELAY] to adjust the scan pause time when

the scan resume setting is set to ‘DELAY.’

• Scan delay time can be set 2 to 20 sec.

[DELAY]
