Icom IC-R9500 [37/194] Basic operations section
![Icom IC-R9500 [37/194] Basic operations section](/views2/1074327/page37/bg25.png)
3-1
BASIC OPERATIONS Section 3
■ When first applying power (CPU resetting) ………………………… 3-2
■ Initial settings …………………………………………………………… 3-2
■ Selecting VFO mode …………………………………………………… 3-3
■ Selecting memory mode ……………………………………………… 3-3
■ Frequency setting ……………………………………………………… 3-4
D Direct frequency entry with the keypad …………………………… 3-4
D Tuning with the main dial …………………………………………… 3-5
D Selecting a tuning step ……………………………………………… 3-5
D Auto tuning step function …………………………………………… 3-6
D
1
⁄4 tuning step function ……………………………………………… 3-6
■ Operating mode selection ……………………………………………… 3-7
■ Volume setting ………………………………………………………… 3-8
■ RF gain adjustment …………………………………………………… 3-8
■ Squelch level adjustment ……………………………………………… 3-8
■ Audio tone adjustment ………………………………………………… 3-9
D Treble level adjustment ……………………………………………… 3-9
D Bass level adjustment ……………………………………………… 3-9
■ Meter indication selection …………………………………………… 3-10
D Meter type selection ……………………………………………… 3-10
