11-11
11
SET MODE
Selects the frequency speech capability when scan
stops; ON or OFF.
NOTE: Output jacks are selected depending on
“SPEECH Mix” settings. See the combination of
“REC SPEECH” and “SPEECH Mix” settings in the
table below.
•ON: The frequency is announced through the
[REC OUT]/[LINE OUT] or [SPEECH OUT]
when scan stops.
• OFF : No speech audio outputs when scan stops.
REC SPEECH
OFF
Selects the speech audio output from the [REC OUT]
or [LINE OUT].
NOTE: See the combination of “REC SPEECH”
and “SPEECH Mix” settings below table.
• All : Outputs the speech audio when speech
operation is performed from the front
panel or depends on above “REC
SPEECH” setting. (default)
• Operation: Outputs the speech audio when speech
operation is performed from the front
panel.
• OFF : No speech audio outputs from [REC
OUT] or [LINE OUT].
SPEECH Mix
All
Selects the operating mode speech capability when a
mode switch is pushed; ON or OFF.
(default: OFF)
When “ON” is selected, the selected operating mode
is announced when a mode switch is pushed.
SPEECH [MODE] SWITCH
OFF
■ Others set mode (continued)
Switch setting Speech operation from front panel Scan stops
REC
SPEECH
OFF
ON
SPEECH
Mix
All
Operation
OFF
All
Operation
OFF
Internal
Speaker
✔
✔
–
✔
✔
–
[REC OUT] /
[LINE OUT]
✔
✔
–
✔
✔
–
[SPEECH OUT]
✔
✔
✔
✔
✔
✔
Internal
Speaker
–
–
–
✔
✔
–
[REC OUT] /
[LINE OUT]
–
–
–
✔
–
–
[SPEECH OUT]
–
–
–
✔
✔
✔
• Combination of REC SPEECH and SPEECH Mix settings
