11-17
11
SET MODE
DD
Load option set mode
Selects file loading condition from All and Select.
(default: Select)
• All : Loads and sets the all following contents.
• Select : Loads and sets the selected contents only.
LOAD Contents
Select
Selects the reference signal setting loading condition
YES and NO. (default: NO).
• YES : Loads and sets the reference signal setting.
•NO: Use the original reference signal setting.
REF IN/OUT, REF Adjust
NO
Selects the IP address and subnet mask setting load-
ing condition YES and NO. (default: NO).
• YES : Loads and sets the IP address and subnet
mask setting.
•NO: Use the original IP address and subnet
mask setting.
IP Address, Subnet Mask
NO
Selects the CI-V address setting loading condition
YES and NO. (default: NO).
• YES : Loads and sets the CI-V address setting.
•NO: Use the original CI-V address setting.
CI-V Address
NO
Selects memory channel contents and other settings
loading condition YES and NO. (default: YES).
• YES : Loads and sets memory channel contents
and other settings.
•NO: Use the original memory channel contents
and other settings.
Other Memory & Settings
YES
