Icom IC-R9500 [167/194] D command table
![Icom IC-R9500 [167/194] D command table](/views2/1074327/page167/bga7.png)
13-3
DD
Command table
13
CONTROL COMMAND
00 — Send frequency data
01 Same as Send mode data
command 06
02 — Read upper/lower frequencies for
selected band
03 — Read operating frequency
04 — Read operating mode
05 — Set operating frequency
06 00 Select LSB
01 Select USB
02 Select AM
03 Select CW
04 Select FSK
05 Select FM
07 Select CW-R
08 Select FSK-R
11 Select S-AM(D)
14 Select S-AM(L)
15 Select S-AM(U)
16 Select P25
07 — Select (Last selected) VFO mode
08 — Select memory mode
0–1219* Select memory channel
*0–999, 1000–1099 (A00–A99),
1100–1199 (S00–S99),
1200–1219 (P0A–P9A)
0–12* Select memory bank
*0–9, 10 (Bank-A), 11 (Bank-S),
12 (Bank-P)
09 — Memory write
0A — Memory to VFO
0B — Memory clear
0C — Read offset frequency
(see p. 13-10 for details)
0D — Set offset frequency
(see p. 13-10 for details)
0E 00 Scan stop
01 Programmed scan (Prog 0)/
memory scan start
02 Programmed scan (Prog 0) start
03 ∂F scan start
04 Auto memory write scan start
12 Fine programmed scan start
13 Fine ∂F scan start
22 Memory scan start
23 Select memory scan start
24 Mode select memory scan start
42 Priority scan (Prio 0) start
A0 Set ∂F scan Fixed frequency ON
AA Set ∂F scan Fixed frequency OFF
A1–A7 Set ∂F scan span (A1=±5 kHz;
A2=±10 kHz; A3=±20 kHz;
A4=±50 kHz; A5=±100 kHz;
A6=±500 kHz; A7=±1 MHz)
B0 Set as non-select channel
B1 Set as select channel
(1–9=★(SEL)1–9; when no data
command is specified, the previous-
ly set number or “★1” is selected)
B2 Set the number for select memory
scan (0=ALL; 1–9=★(SEL)1–9
D0 Set scan resume OFF
0E D1 Set scan resume ON
(Close Timer)
D3 Set scan resume ON
(Close and Delay)
10 Turn duplex OFF. (Simplex)
11 Turn duplex ON. (DUP–)
12 Turn duplex ON. (DUP+)
10 00 Select 1 Hz tuning step
01 Select 10 Hz tuning step
02 Select 100 Hz tuning step
03 Select 1 kHz tuning step
04 Select 2.5 kHz tuning step
05 Select 5 kHz tuning step
06 Select 6.25 kHz tuning step
07 Select 9 kHz tuning step
08 Select 10 kHz tuning step
09 Select 12.5 kHz tuning step
10 Select 20 kHz tuning step
11 Select 25 kHz tuning step
12 Select 100 kHz tuning step
13 Select 1 MHz tuning step
14 Select Prog tuning step
11 — Select/read attenuator (00=OFF;
06=6 dB; 10=10 dB; 12=12 dB;
18=18 dB; 20=20 dB; 24=24 dB;
30=30 dB)
12 00 Select/read the antenna below
01 30 MHz. (00=HF ANT1,
02 01=HF ANT2, 02=HF ANT3)
13 00 Announce with voice synthesizer
01 (00=all data; 01=frequency and
02 S-meter level; 02=receive mode)
14 01 + Level data [AF] level setting
(0=max. CCW to 255=max. CW)
02 + Level data [RF] level setting
(0=max. CCW to 255=11 o’clock)
03 + Level data [SQL] level setting
(0=11 o’clock to 255=max. CW)
06 + Level data [NR] level setting
(0=min. to 255=max.)
07 + Level data Left [TWIN PBT] setting or IF shift
setting (0=max. CCW, 128=center,
255=max. CW)
08 + Level data Right [TWIN PBT] setting
(0=max. CCW, 128=center,
255=max. CW)
09 + Level data [CW PITCH] setting
(0=300 Hz, 128=600 Hz,
255=900 Hz; 5 Hz steps)
0D + Level data [NOTCH1] setting
(0=low freq. to 255=high freq.)
11 + Level data [AGC] control setting (0=max.
CCW to 255=max. CW)
12 + Level data [NB] control setting
(0=max. CCW to 255=max. CW)
18 + Level data [CONTRAST] setting (0=max.
CCW to 255=max. CW)
19 + Level data [BRIGHT] setting
(0=max. CCW to 255=max. CW)
1A + Level data [NOTCH2] setting
(0=low freq. to 255=high freq.)
1B + Level data [BASS] setting
(0=max. CCW to 255=max. CW)
1C + Level data [TREBLE] setting
(0=max. CCW to 255=max. CW)
Command Sub command Description Command Sub command Description
