13-6
DD
Command table (continued)
13
CONTROL COMMAND
1A 050094 Send/read the LCD unit brightness
with dimmer OFF condition
(0=0% to 255=100%)
050095 Send/read the key backlight with
dimmer OFF condition
(0=0% to 255=100%)
050096 Send/read the LCD contrast with
dimmer ON condition
(0=0% to 255=100%)
050097 Send/read the LCD brightness
with dimmer ON condition
(0=0% to 255=100%)
050098 Send/read the LCD unit brightness
with dimmer ON condition
(0=0% to 255=100%)
050099 Send/read the key backlight with
dimmer ON condition
(0=0% to 255=100%)
050100 Send/read scope max. hold
(0=OFF, 1=ON)
050101 Send/read scope center frequen-
cy set (0=Filter center, 1=Carrier
point center, 2=Carrier point cen-
ter (Abs. Freq.))
050102 Send/read waveform color for
receiving signal
(see p. 13-11 for details)
050103 Send/read waveform color for
max. hold
(see p. 13-11 for details)
050104 Send/read marker color for receiv-
ing signal
(see p. 13-11 for details)
050105 Send/read marker color for max.
hold (see p. 13-11 for details)
050106 Send/read scope peak excursion
(0=0 dB to 80=80 dB)
050107 Send/read scope peak threshold
(0=–100 dB to 100=0 dB)
050108 Send/read voice recorder’s short
play time (3=3 sec. to 10=10 sec.)
050109 Send/read voice recorder short
record time
(5=5 sec. to 30=30 sec.)
050110 Send/read voice recorder’s
recording quality
(0=SQ1 (8 kHz), 1=SQ2 (12 kHz),
2=HQ1 (16 kHz) 3=HQ2(24 kHz)
4=SHQ (48 kHz))
050111 Send/read REC remote set
(0=OFF, 1=ON)
050112 Send/read SPEECH Mix set
(0=OFF, 1=Operation, 2=All)
050113 Send/read speech mix level
(0=0% (Receive audio only) to
255=100% (Speech audio only))
050114 Send/read memory bank limit set
for memory channel selection
(0=OFF, 1=ON)
050115 Send/read memory bank limit set
for memory scan (0=OFF, 1=ON)
050116 Send/read memory bank name
(Bank-0) (see p. 13-10 for details)
050117 Send/read memory bank name
(Bank-1) (see p. 13-10 for details)
1A 050118 Send/read memory bank name
(Bank-2) (see p. 13-10 for details)
050119 Send/read memory bank name
(Bank-3) (see p. 13-10 for details)
050120 Send/read memory bank name
(Bank-4) (see p. 13-10 for details)
050121 Send/read memory bank name
(Bank-5) (see p. 13-10 for details)
050122 Send/read memory bank name
(Bank-6) (see p. 13-10 for details)
050123 Send/read memory bank name
(Bank-7) (see p. 13-10 for details)
050124 Send/read memory bank name
(Bank-8) (see p. 13-10 for details)
050125 Send/read memory bank name
(Bank-9) (see p. 13-10 for details)
050126 Send/read memory bank name
(Bank-A) (see p. 13-10 for details)
050127 Send/read memory bank name
(Bank-S) (see p. 13-10 for details)
050128 Set/read FFT scope averaging set
for FSK decoder
(0=OFF, 1=2, 2=3, 3=4)
050129 Set/read FFT scope waveform
color set for FSK decoder
(see p. 13-11 for details)
050130 Send/read FSK decode USOS
(0=OFF, 1=ON)
050131 Send/read FSK decode new line
code
(0=CR,LF,CR+LF, 1=CR+LF)
050132 Send/read clock selection for time
stamp (0=Local time, 1=Clock 2)
050133 Send/read frequency stamp
(0=OFF, 1=ON)
050134 Send/read FSK received text font
color (see p. 13-11 for details)
050135 Send/read time stamp text font
color (see p. 13-11 for details)
050136 Send/read skip scan set
(0=OFF, 1=ON)
050137 Send/read auto memory scan
memory clear set (0=OFF,
1=[AUTO] Long Push, 2=ON)
050138 Send/read auto scan screen set
when scan start (0=OFF, 1=ON)
050139 Send/read NB1 depth
(0=1 to 9=10)
050140 Send/read NB1 width
(0=0 to 255=100)
050141 Send/read NB2 depth
(0=1 to 9=10)
050142 Send/read NB2 width
(0=0 to 255=100)
050143 Send/read TS (1 Hz) as selectable
tuning step for FM
(0=OFF, 1=ON)
050144 Send/read TS (10 Hz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050145 Send/read TS (100 Hz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050146 Send/read TS (1 kHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
Command Sub command Description Command Sub command Description
