Icom IC-R9500 [137/194] Display set mode
![Icom IC-R9500 [137/194] Display set mode](/views2/1074327/page137/bg89.png)
11-9
11
SET MODE
Sets the introductory text, up to 10-character long,
displayed in the opening screen.
Capital letters, small letters, numerals, some symbols
(– / . @) and spaces can be used.
z Push [F-5•EDIT] to select the comment edit condi-
tion.
• The cursor under the 1st character blinks.
x Push [ABC], [abc], [123] or [Symbol] to select the
character group, then rotate the main dial to select
the character.
• Push [ABC] or [abc] to toggle capital and small letters.
• Push [123] or [Symbol] to toggle numerals and sym-
bols.
• Push [F-1•Ω] or [F-2•≈] for cursor movement.
• Push [F-3•DEL] to delete the selected character.
• Push [F-4•SPACE] to input a space.
• Using the receiver’s keypad, [0]–[9], can also enter nu-
merals.
c Push [EXIT/SET] to set the comment.
Opening Comment
Select “ON” when the external display is connected.
(default: OFF)
• At least 800×600 pixel resolution is required for the dis-
play.
External Display
OFF
Selects the suitable pulse level for the connected ex-
ternal display from H and L. (default: H)
External Display Sync Pulse
H
Turns the opening message screen indication capa-
bility ON and OFF. (default: ON)
Opening Message
ON
■ Display set mode (continued)
