Icom IC-R9500 [74/194] D scope set mode continued

5-8

RECEIVE FUNCTIONS

Set the next peak excursion level from 0 to 80 dB in

1 dB steps. (default: 6 dB)

If the difference between the signal peak and adja-

cent minimum values is less than the set level, it will

not be found as the next peak level when [NEXTΩ] or

[NEXT≈] is pushed.

Peak Excursion

6dB

Set the next peak threshold level from 0 to –100 dB

in 1 dB steps. (default: –90dB)

If the difference between the signal and last peak sig-

nal values is more than the set level, it will not be

found as the next peak level when [NEXTΩ] or

[NEXT≈] is pushed.

Peak Threshold

–90dB

Scope set mode (continued)
