Icom IC-R9500 [29/194] Required connections

■ Required connections

Rear panel

HF Antenna 1, 2, 3 (p. 2-3)Antenna 1, 2 (p. 2-3)

Connects the VHF,

UHF wide band anten-

nas.

ANT1: 30–1150 MHz,

ANT2: 1150–3335 MHz

Select the active antenna connector. (p.9-3)

[Example]: HF ANT1 for 3.5, 7 MHz bands, HF ANT 2 for 14, 18

MHz bands, ANT3 for 24, 28 MHz band.

Ground (p. 2-2)

Ground connection

AC outlet

R WARNING:

Use the supplied

AC power cable

only.

[VIDEO IN], [VIDEO OUT]

TV jumper cable must be connec-

ted when internal TV tuner and

LCD are in use (except USA ver-

sions).

No signals come out from [VIDEO

OUT] for USA versions.

2-5

INSTALLATION AND CONNECTIONS
