Icom IC-R9500 [172/194] D command table continued
![Icom IC-R9500 [172/194] D command table continued](/views2/1074327/page172/bgac.png)
DD
Command table (continued)
13-8
13
CONTROL COMMAND
1A 050191 Send/read TS (1 kHz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050192 Send/read TS (2.5 kHz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050193 Send/read TS (5 Hz) as selectable
tuning step for SSB
(0=OFF, 1=ON)
050194 Send/read TS (6.25 kHz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050195 Send/read TS (9 kHz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050196 Send/read TS (10 kHz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050197 Send/read TS (12.5 kHz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050198 Send/read TS (20 kHz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050199 Send/read TS (25 kHz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050200 Send/read TS (100 kHz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050201 Send/read TS (1 MHz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050202 Send/read TS (PROG) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050203 Send/read TS (1 Hz) as selectable
tuning step for CW
(0=OFF, 1=ON)
050204 Send/read TS (10 Hz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050205 Send/read TS (100 Hz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050206 Send/read TS (1 kHz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050207 Send/read TS (2.5 kHz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050208 Send/read TS (5 Hz) as selectable
tuning step for CW
(0=OFF, 1=ON)
050209 Send/read TS (6.25 kHz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050210 Send/read TS (9 kHz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050211 Send/read TS (10 kHz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050212 Send/read TS (12.5 kHz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
1A 050213 Send/read TS (20 kHz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050214 Send/read TS (25 kHz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050215 Send/read TS (100 kHz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050216 Send/read TS (1 MHz) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050217 Send/read TS (PROG) as selec-
table tuning step for CW
(0=OFF, 1=ON)
050218 Send/read TS (1 Hz) as selectable
tuning step for FSK
(0=OFF, 1=ON)
050219 Send/read TS (10 Hz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050220 Send/read TS (100 Hz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050221 Send/read TS (1 kHz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050222 Send/read TS (2.5 kHz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050223 Send/read TS (5 Hz) as selectable
tuning step for FSK
(0=OFF, 1=ON)
050224 Send/read TS (6.25 kHz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050225 Send/read TS (9 kHz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050226 Send/read TS (10 kHz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050227 Send/read TS (12.5 kHz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050228 Send/read TS (20 kHz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050229 Send/read TS (25 kHz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050230 Send/read TS (100 kHz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050231 Send/read TS (1 MHz) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050232 Send/read TS (PROG) as selec-
table tuning step for FSK
(0=OFF, 1=ON)
050233 Send/read TS (1 Hz) as selectable
tuning step for P25
(0=OFF, 1=ON)
050234 Send/read TS (10 Hz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
Command Sub command Description Command Sub command Description
