14-2
■ Specifications
DD
General
• Frequency coverage (unit: MHz) :
USA 0.005000–821.999999, 851.000000–866.999999
896.000000–3335.000000
France 0.0050000–29.999999, 50.200000–51.200000,
87.500000–108.000000, 144.000000–146.000000,
430.000000–440.000000, 1240.000000–1300.000000
Europe, U.K., USA-01, EXP, Australia 0.005000–3335.000000
• Operating mode : USB, LSB, CW, FSK, AM, FM, WFM, P25
(with UT-122)
• Number of memory channels : 1220 (1000 regular channels, 100 auto memory write
channels, 100 skip channels, 20 scan edge channels)
• Antenna connector : Type-N×2 (antenna impedance: 50 Ω),
SO-239×1 (antenna impedance: 50 Ω),
Phono (RCA)×1 (antenna impedance: 500 Ω)
•Operating temperature range : 0˚C to +50˚C; +32˚F to +122˚F
• Frequency stability : Less than ±0.05 ppm (approx. 5 min. after from turn the
main power, [I/O], ON, 0–50˚C; 32–122˚F)
• Frequency resolution : 1Hz
• Power supply requirement : 100 V, 120 V, 230 V, 240 V AC
• Power consumption :
Receive Stand-by Less than 100 VA
Max. audio Less than 100 VA
• Dimensions (projections not included) : 424×149×340 mm; 16
11
⁄16×5
7
⁄8×13
3
⁄8 in
•Weight : Approx. 20 kg; 44 lb
• ACC connector : 8-pin DIN connector
•DATA IN connector : 8-pin DIN connector
• Display* : 7-inch (diagonal) TFT color LCD (800×480)
• EXT-DISPLAY connector : D-sub 15S
• RS-232C connector : D-sub 9-pin
• VIDEO IN connector : Phono (RCA)
• VIDEO OUT connector : Phono (RCA)
• SPEECH OUT connector : Phono (RCA)
• LINE OUT connector : Phono (RCA)
• USB connector : USB (Universal Serial Bus)1.1/2.0
• CI-V connector : 2-conductor 3.5 (d) mm (
1
⁄8″)
• ANT-SEL connector : 3-conductor 3.5 (d) mm (
1
⁄8″)
• DET OUT connector : 3-conductor 3.5 (d) mm (
1
⁄8″)
• EXT-SP connectors : 2-conductor 3.5 (d) mm (
1
⁄8″)/8 Ω
• REC REMOTE connector : 3-conductor 3.5 (d) mm (
1
⁄8″)×2
(Front and rear panels)
• REC OUT connector : 3-conductor 3.5 (d) mm (
1
⁄8″)
• PHONES connector : 3-conductor 3.5 (d) mm (
1
⁄8″)
14
SPECIFICATIONS AND OPTIONS
All stated specifications are typical and subject to change without notice or obligation.
