Icom IC-R9500 [45/194] Audio tone adjustment

3-9

■ Audio tone adjustment

NOTE: When [TREBLE] or [BASS] control is ad-

justed CCW, audio output decreases from [S/P DIF

OUT], [ACC], [LINE OUT] or [REC OUT]. This is

normal, not a malfunction.

Treble level adjustment

➥ Rotate [TREBLE] control clockwise to increase,

counterclockwise to decrease the treble level of the

audio tone.

Bass level adjustment

➥ Rotate [BASS] control clockwise to increase, coun-

terclockwise to decrease the bass level of the audio

tone.

Tone level

increases

Tone level

decreases

[BASS]

Tone level

increases

Tone level

decreases

[TREBLE]

BASIC OPERATIONS
