Icom IC-R9500 [4/194] Supplied accessories
![Icom IC-R9500 [4/194] Supplied accessories](/views2/1074327/page4/bg4.png)
q AC power cable* ………………………………… 1
w Carrying handles ……………………………… 1 set
e Spare fuse (FGB 1 A) …………………………… 1
r Spare fuse
FGB 4 A (100 V/120 V versions) ………………… 1
0234002MXP (230 V/240 V versions)
…………… 1
t RCA plugs ………………………………………… 4
y DC power plug …………………………………… 1
u 2-conductor
1
⁄8″ plugs …………………………… 7
i 3-conductor
1
⁄8″ plugs …………………………… 1
o 8 pin ACC plugs …………………………………… 2
!0 Screws for side plate
†
…………………………… 4
!1 Hiding screws for screw hole
†
…………………… 2
!2 Ferrite bead
‡
……………………………………… 3
*May differ from that shown according to version.
†
These screw are used when removing rack mounting han-
dles.
‡
These are used when connecting cables to [DATA IN], [LAN]
or [USB].
iii
SUPPLIED ACCESSORIES
q
o
!0
!1
tyu i
e
w
r
(FH M4×16 mm)
(FH M4×12 mm)
(PH M4×8 mm)
PH: Pan head
FH: Flat head
!2
(see p. 2-7 for installation details)
