Icom IC-R9500 [171/194] D command table continued
![Icom IC-R9500 [171/194] D command table continued](/views2/1074327/page171/bgab.png)
13-7
DD
Command table (continued)
13
CONTROL COMMAND
1A 050147 Send/read TS (2.5 kHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050148 Send/read TS (5 Hz) as selectable
tuning step for FM
(0=OFF, 1=ON)
050149 Send/read TS (6.25 kHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050150 Send/read TS (9 kHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050151 Send/read TS (10 kHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050152 Send/read TS (12.5 kHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050153 Send/read TS (20 kHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050154 Send/read TS (25 kHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050155 Send/read TS (100 kHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050156 Send/read TS (1 MHz) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050157 Send/read TS (PROG) as selec-
table tuning step for FM
(0=OFF, 1=ON)
050158 Send/read TS (1 Hz) as selectable
tuning step for WFM
(0=OFF, 1=ON)
050159 Send/read TS (10 Hz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050160 Send/read TS (100 Hz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050161 Send/read TS (1 kHz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050162 Send/read TS (2.5 kHz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050163 Send/read TS (5 Hz) as selectable
tuning step for WFM
(0=OFF, 1=ON)
050164 Send/read TS (6.25 kHz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050165 Send/read TS (9 kHz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050166 Send/read TS (10 kHz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050167 Send/read TS (12.5 kHz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050168 Send/read TS (20 kHz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
1A 050169 Send/read TS (25 kHz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050170 Send/read TS (100 kHz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050171 Send/read TS (1 MHz) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050172 Send/read TS (PROG) as selec-
table tuning step for WFM
(0=OFF, 1=ON)
050173 Send/read TS (1 Hz) as selectable
tuning step for AM
(0=OFF, 1=ON)
050174 Send/read TS (10 Hz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050175 Send/read TS (100 Hz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050176 Send/read TS (1 kHz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050177 Send/read TS (2.5 kHz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050178 Send/read TS (5 Hz) as selectable
tuning step for AM
(0=OFF, 1=ON)
050179 Send/read TS (6.25 kHz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050180 Send/read TS (9 kHz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050181 Send/read TS (10 kHz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050182 Send/read TS (12.5 kHz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050183 Send/read TS (20 kHz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050184 Send/read TS (25 kHz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050185 Send/read TS (100 kHz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050186 Send/read TS (1 MHz) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050187 Send/read TS (PROG) as selec-
table tuning step for AM
(0=OFF, 1=ON)
050188 Send/read TS (1 Hz) as selectable
tuning step for SSB
(0=OFF, 1=ON)
050189 Send/read TS (10 Hz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
050190 Send/read TS (100 Hz) as selec-
table tuning step for SSB
(0=OFF, 1=ON)
Command Sub command Description Command Sub command Description
