11-7
11
SET MODE
■ ACC set mode
Sets the speech audio output level from [SPEECH
OUT] from 0 to 100% in 1% steps.
• Outputs approx. 200 mV at 50% (default) setting.
SPEECH OUT Level
50
%
Sets the desired output level of [S/P DIF OUT], from 0
to 100% in 1% steps. (default: 100%)
S/PDIF Output Level
100
%
Sets the output level for an external meter indication
from 0 to 100% range in 1% steps.
• Approx. 2.5 V at 50% (default) setting for full-scale indica-
tion. (4.7 kΩ impedance)
External Meter Level
50
%
External Meter Level
50
%
Selects the receiver’s reference signal condition from
IN, OFF and OUT.
•IN: Use an external reference signal for the IC-
R9500.
• OFF : No input or output of the reference signal.
(default)
• OUT : Outputs the IC-R9500 reference signal to
externally connected equipment(s) for their
reference.
NOTE: If the applied reference signal is off-fre-
quency, or no signal is applied with “IN” selection,
the IC-R9500 will not work properly. Select “OFF”
or “OUT” then reboot the IC-R9500.
External Meter Level
50
%
Reference IN/OUT
OFF
Adjusts the internal reference frequency within 0 to
100% in 1% steps during frequency calibration.
NOTE: Default setting is different for each receiver.
REF Adjust
40
%
Turns the control signal of external equipment output
capability ON and OFF. (default: OFF)
• OFF : No signal output from [REC REMOTE]
jacks. (default)
•ON: The [REC REMOTE] jacks shorts to
ground when receiving a signal or the
squelch is open.
REC Remote (External)
OFF
Selects the squelch condition output for an external
meter indication from pin 8 of [ACC].
• Signal : Outputs the receiving signal strength
level during receiving. (default)
• Signal+SQL: Outputs the receiving signal strength
level during receiving and outputs
squelch open/close condition.
External Meter Output
Signal
