13-5
DD
Command table (continued)
13
CONTROL COMMAND
1A 050042 Send/read P25 received ID pop-
up indication setting
(0=OFF, 1=ON(Dec), 2=ON(Hex))
050043 Send/read screen saver set
(0=OFF, 1=15 min., 2=30 min.,
3=60 min.)
050044 Send/read output signal setting for
external display (0=OFF, 1=ON)
050045 Send/read external display syn-
chronous pulse level setting
(0=L, 1=H)
050046 Send/read opening message indi-
cation (0=OFF, 1=ON)
050047 Send/read opening message con-
tents (see p. 13-10 for details)
050048 Send/read date
(20000101=1st Jan. 2000 to
20991231=31st Dec. 2099)
050049 Send/read time
(0000=00:00 to 2359=23:59)
050050 Send/read clock 2 function
(0=OFF, 1=ON)
050051 Send/read offset time for clock 2
(240001=–24:00 to 240000=+24:00)
050052 Send/read clock 2 name
(Up to 3-character; see p. 13-10)
050053 Send/read calibration marker
(0=OFF, 1=ON)
050054 Send/read confirmation beep
(0=OFF, 1=ON)
050055 Send/read beep audio frequency
(50=500 Hz to 200=2000 Hz)
050056 Send/read panel lock function set
(0=ALL, 1=KEY)
050057 Send/read speech language
(0=English, 1=Japanese)
050058 Send/read speech speed
(0=Slow, 1=Fast)
050059 Send/read S-level speech
(0=OFF, 1=ON)
050060 Send/read speech with a mode
switch operation (0=OFF, 1=ON)
050061 Send/read REC Speech set
(0=OFF, 1=ON)
050062 Send/read Speech Mix function
set (0=OFF, 1=Operation, 2=All)
050063 Send/read main dial auto TS
(0=OFF, 1=Low, 2=High)
050064 Send/read main dial click function
mode set (0=Manual, 1=Auto)
050065 Send/read main dial click function
set
(When above is Manual; 0=OFF,
1=ON or Auto; 0=OFF, 1=Auto)
050066 Send/read main dial click (set
mode, etc) function
(0=OFF, 1=ON)
050067 Send/read main dial operation
during scan (0=OFF, 1=Up/Down)
050068 Send/read AFC limit set
(0=OFF, 1=ON)
050069 Send/read SSB/CW synchronous
tuning function (0=OFF, 1=ON)
050070 Send/read CW normal side set
(0=LSB, 1=USB)
050071 Send/read APF type
(0=SHARP, 1=SOFT)
1A 050072 Send/read CI-V transceive set
(0=OFF, 1=ON)
050073 Send/read RS-232C function
(0=CI-V, 1=Decode)
050074 Send/read RS-232C decode
speed (0=300, 1=1200, 2=4800,
3=9600, 4=19200)
050075 Send/read keyboard type
(00=English, 01=Japanese,
02=United Kingdom, 03=French,
04=French (Canadian),
05=German, 06=Portuguese,
07=Portuguese (Brazilian),
08=Spanish, 09=Spanish (Latin
American), 10=Italian)
050076 Send/read keyboard repeat delay
(10=100 msec. to 100=1000 msec.)
050077 Send/read keyboard repeat speed
(0=2.0 cps to 31=30.0 cps)
050078 Send/read IP address set
(0000000000000001=0.0.0.1 to
0255025502550254=255.255.25
5.254)
050079 Send/read subnet mask
(1=128.0.0.0 to
30=255.255.255.252)
050080 Send/read TV type
(0=NTSC M, 1=PAL B/G, 2=PAL I,
3=PAL D, 4=SECAM K)
050081 Send/read the LCD contrast of the
video signal from [VIDEO IN]
(0=0% to 255=100%)
050082 Send/read the LCD brightness of
the video signal from [VIDEO IN]
(0=0% to 255=100%)
050083 Send/read the saturation of the
video signal from [VIDEO IN]
(0=0% to 255=100%)
050084 Send/read the hue of the video
signal from [VIDEO IN]
(0=0% to 255=100%)
050085 Send/read the frame trimming of
the video signal from [VIDEO IN].
(0=OFF, 1=ON)
050086 Send/read the wide screen set.
(0=OFF, 1=ON)
050087 Send/read the output video signal
from [DATA IN]
(0=VIDEO IN, 1=LCD)
050088 Send/read the width of the output
video signal from [DATA IN]
(0=1 (narrow) to 3=4 (wide))
050089 Send/read setup of the output
video signal from [DATA IN]
(0=0IRE (JPN NTSC), 1=7.5IRE
(USA NTSC))
050090 Send/read output saturation level
from [DATA IN]
(0=0% to 255=100%)
050091 Send/read output hue level from
[DATA IN]. (0=0% to 255=100%)
050092 Send/read the LCD contrast with
dimmer OFF condition
(0=0% to 255=100%)
050093 Send/read the LCD brightness
with dimmer OFF condition
(0=0% to 255=100%)
