Icom IC-R9500 [85/194] Voice recorder functions section
![Icom IC-R9500 [85/194] Voice recorder functions section](/views2/1074327/page85/bg55.png)
6-1
VOICE RECORDER FUNCTIONS Section 6
■ About digital voice recording ………………………………………… 6-2
■ Recording received audio ……………………………………………… 6-3
D Regular recording …………………………………………………… 6-3
■ Playing the recorded audio …………………………………………… 6-4
D Regular playing ……………………………………………………… 6-4
■ Erasing the recorded contents ………………………………………… 6-4
■ Selecting the CF memory card or USB-Memory …………………… 6-4
■ Short recording ………………………………………………………… 6-5
D Recording …………………………………………………………… 6-5
D Playing back ………………………………………………………… 6-5
■ Voice set mode ………………………………………………………… 6-6
