Icom IC-R9500 [173/194] D command table continued
![Icom IC-R9500 [173/194] D command table continued](/views2/1074327/page173/bgad.png)
13-9
13
CONTROL COMMAND
DD
Command table (continued)
1A 050235 Send/read TS (100 Hz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050236 Send/read TS (1 kHz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050237 Send/read TS (2.5 kHz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050238 Send/read TS (5 Hz) as selectable
tuning step for P25
(0=OFF, 1=ON)
050239 Send/read TS (6.25 kHz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050240 Send/read TS (9 kHz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050241 Send/read TS (10 kHz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050242 Send/read TS (12.5 kHz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050243 Send/read TS (20 kHz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050244 Send/read TS (25 kHz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050245 Send/read TS (100 kHz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050246 Send/read TS (1 MHz) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050247 Send/read TS (PROG) as selec-
table tuning step for P25
(0=OFF, 1=ON)
050248 Send/read CW pitch set
(0=300 Hz to 120=900 Hz in 5 Hz
steps)
050249 Send/read FSK RX frequency
(0=Mark(Space), 1=Mark/Space
Center)
050250 Send/read FSK tone frequency
(0=1275 Hz, 1=1500 Hz,
2=1615 Hz, 3=2125 Hz)
050251 Send/read FSK shift width
(0=170 Hz, 1=200 Hz, 2=425 Hz,
3=800 Hz,4=850 Hz )
08 Send/read DSP filter shape
(0= sharp, 1= soft)
09 Send/read roofing filter set
(FM/AM/SSB/CW/FSK; 0=3 kHz,
1=6 kHz, 2=15 kHz, 3=50 kHz,
WFM; 4=240 kHz, P25; 2=15
kHz)
0A Send/read manual notch1 width
(0=Wide, 1=Mid., 2=Nar.)
0B Send/read manual notch2 width
(0=Wide, 1=Mid., 2=Nar.)
1B 01 Set/read TSQL tone frequency.
(see p. 13-10 for details)
02 Set/read DTCS squelch code
(see p. 13-10 for details)
03 Set/read NAC squelch code
(see p. 13-11 for details)
04 Set/read TGID for selective
squelch (see p. 13-11 for details)
05 Set/read UNIT ID for selective
squelch (see p. 13-11 for details)
1D 00 Send/read remote function set
(0=OFF, 1=REMOTE1 (locks VRs
only), 2=REMOTE2 (locks VRs.
Keys,and dials)
Command Sub command Description Command Sub command Description
