PROBLEM POSSIBLE CAUSE SOLUTION REF.
Programmed scan does
not stop.
Scan does not start.
(Programmed scan)
(Memory scan)
(Select memory scan)
(Mode select memory scan)
(∂F scan)
(Auto memory write scan)
• Squelch is open.
•
The same frequencies have been programmed
in scan edge memory channels PxA and PxB.
•2 or more memory channels have not been
programmed.
•2 or more memory channels have not been
designated as select channels.
•2 or more memory channels with desired
mode have not been programmed.
• The center frequency for ∂F scan does not
programmed.
• Auto write bank is full.
• Readjust the [SQL] threshold.
• Program different frequencies in scan edge
memory channel PxA and PxB.
• Program more than 2 memory channels.
• Designate more than 2 memory channels as
select channels for the scan.
• Program more than 2 memory channels with
desired operating mode.
• Program the center frequency for ∂F scan.
• Clear the memory channels of auto write bank.
pgs. 3-8,
8-3
p. 8-6
pgs. 7-4,
8-11
p. 8-12
pgs. 7-4,
8-14
p. 8-8
pgs. 7-7,
8-4
PROBLEM POSSIBLE CAUSE SOLUTION REF.
No indication appears on
the display.
The displayed frequency
does not change properly.
The key operation on the
front panel does not func-
tion.
• The LCD settings are wrong in the LCD set
mode.
•The panel lock with display sleep function is
activated.
• The dial lock function is activated.
• The remote control operation is active.
• The panel lock function is activated.
• The remote control operation is active.
• Set LCD settings properly in the set mode.
• Push [PANEL LOCK] to turn the function OFF.
•
Push [LOCK] to turn the function OFF.
• Push [LOCAL] to cancel the remote control
operation.
• Push [PANEL LOCK] to turn the function OFF.
• Push [LOCAL] to cancel the remote control
operation.
p. 11-26
p. 9-2
p. 9-2
p. 1-2
p. 9-2
p. 1-2
PROBLEM POSSIBLE CAUSE SOLUTION REF.
The voice recorder cannot
record.
The voice recorder stops
recording.
• The selected memory media is full.
• 512 files already exist in folder.
• The maximum file name (V∗∗∗∗999.wav)
exists in folder.
(Example: V0424
999.wav, V1116999.wav)
• The recording memory media is full.
• The recording file size is at maximum (2 GB).
•
Select a different memory media or clear the
unnecessary files.
•
Clear the unnecessary files.
•
Delate the file
(V∗∗∗∗999.wav)
, or change the
file name.
•
Select a different memory media or clear the
unnecessary files.
• Select a lower sound quality for long duration
recording.
pgs. 6-4,
11-22
p. 11-22
pgs. 6-4,
11-20,
11-22
p. 6-4
p. 6-6
PROBLEM POSSIBLE CAUSE SOLUTION REF.
Format error appears
when formatting in FAT32
Format error appears
when formatting in FAT
• The inserted memory media capacity is small-
er than 64 MB.
• The inserted memory media capacity is larger
than 2 GB.
•
Insert a memory media larger than 64 MB or
select the FAT format.
•
Insert a memory media smaller than 2 GB or
select the FAT32 format.
p. 11-23
p. 11-23
