- 9 -
44 SATA_DOM0 SATA port 0 DOM support jumper
45 CASE_OPEN Case open intrusion alert header
46 LED5 LSIrmwarereadinessLED
47 SATA1 SATA 3 6Gb/s connector
48 SATA_DOM1 SATA port 1 DOM support jumper
49 SATA2/3/4/5 SATA 3 6Gb/s connectors
50 SSATA0/1/2/3 SATA 3 6Gb/s connectors
51 CLR_CMOS Clear CMOS jumper
52 F_USB3 USB 3.0 header
53 IPMB IPMB connector
54 F_USB2 USB 2.0 header
55 TPM TPM module connector
56 COM2 Serial port cable header
57 SPDIF_OUT1 S/PDIF out header
58 SPDIF_IN1 S/PDIF in header
59 F_AUDIO Front audio connector
60 PCIE_1 PCI Express x8 slot
61 S3_MASK S3 Power On Select jumper
62 PCIE_2 PCI Express x16 slot
63 LAN1_LED LAN #1 Active/Link connector
64 LAN2_LED LAN #2 Active/Link connector
65 PCIE_3 PCI Express x8 slot
66 PCIE_4 PCI Express x16 slot
67 PCIE_5 PCI Express x8 slot
68 PCIE_6 PCI Express x16 slot
69 DIMM_P1_F1 Channel 3 slot 1 (for secondary CPU)
70 DIMM_P1_F0 Channel 3 slot 0 (for secondary CPU)
71 DIMM_P1_E1 Channel 4 slot 1 (for secondary CPU)
72 DIMM_P1_E0 Channel 4 slot 0 (for secondary CPU)
73 LED_BMC BMCrmwarereadinessLED
74 BAT Battery socket
75 BUZZER1 Buzzer
CAUTION! If a SATA type hard drive is connected to the motherboard, please ensure the jumper is
closed and set to 2-3 pins (Default setting), in order to reduce any risk of hard disk damage. Please
refer to Page 39 for SATA_DOM0 and SATA_DOM1 jumper setting instruction.
