Daikin RXYQ22M7W1B [107/182] Capacity tables
![Daikin RXYQ22M7W1B [107/182] Capacity tables](/views2/1707499/page107/bg6b.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
106
3 Capacity tables
3-2 Heating capacity
3-2-7 18HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 225
-19.8 -20.0 31.9 16.6 30.1 15.4 28.3 14.4 27.3 13.8 26.4 13.3 24.6 12.3
-18.8 -19.0 31.9 16.0 30.1 14.9 28.3 13.8 27.3 13.3 26.4 12.8 24.6 11.8
-16.7 -17.0 31.9 14.9 30.1 13.9 28.3 12.9 27.3 12.5 26.4 12.0 24.6 11.1
-14.7 -15.0 31.9 14.0 30.1 13.0 28.3 12.2 27.3 11.7 26.4 11.3 24.6 10.4
-12.6 -13.0 31.9 13.1 30.1 12.3 28.3 11.5 27.3 11.1 26.4 10.7 24.6 9.87
-10.5 -11.0 31.9 12.4 30.1 11.6 28.3 10.9 27.3 10.5 26.4 10.1 24.6 9.36
-9.5-10.031.912.130.111.328.310.627.310.226.49.8524.69.13
-8.5 -9.1 31.9 11.8 30.1 11.1 28.3 10.3 27.3 9.98 26.4 9.63 24.6 8.93
-7.0 -7.6 31.9 11.4 30.1 10.7 28.3 9.96 27.3 9.62 26.4 9.29 24.6 8.62
-5.0 -5.6 31.9 10.8 30.1 10.2 28.3 9.51 27.3 9.19 26.4 8.87 24.6 8.25
-3.0 -3.7 31.9 10.4 30.1 9.74 28.3 9.12 27.3 8.82 26.4 8.52 24.6 7.92
0.0 -0.731.99.7330.19.1528.38.5827.38.3026.48.0224.67.47
3.0 2.2 31.9 9.19 30.1 8.65 28.3 8.12 27.3 7.85 26.4 7.59 24.6 7.08
5.0 4.1 31.9 8.87 30.1 8.35 28.3 7.84 27.3 7.59 26.4 7.34 24.6 6.85
7.0 6.0 31.9 8.58 30.1 8.08 28.3 7.59 27.3 7.35 26.4 7.11 24.6 6.64
9.0 7.9 31.9 8.30 30.1 7.83 28.3 7.36 27.3 7.13 26.4 6.90 24.6 6.44
11.0 9.8 31.98.0530.17.5928.37.1427.36.9226.46.7024.66.26
13.0 11.8 31.9 7.80 30.1 7.36 28.3 6.93 27.3 6.71 26.4 6.50 24.6 6.08
15.0 13.7 31.9 7.58 30.1 7.16 28.3 6.74 27.3 6.53 26.4 6.33 24.6 5.92
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
