Daikin RXYQ22M7W1B [152/182] Capacity tables
![Daikin RXYQ22M7W1B [152/182] Capacity tables](/views2/1707499/page152/bg98.png)
18
3
• Systems • Outdoor Units
151
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-22 48HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 600
-19.8 -20.0 75.9 40.4 75.7 41.2 75.0 41.5 72.6 40.0 70.2 38.4 65.4 35.4
-18.8 -19.0 78.7 40.9 78.5 41.7 75.0 39.8 72.6 38.3 70.2 36.8 65.4 33.9
-16.7 -17.0 84.2 41.9 79.8 39.4 75.0 36.6 72.6 35.3 70.2 33.9 65.4 31.3
-14.7 -15.0 84.6 39.1 79.8 36.5 75.0 34.0 72.6 32.7 70.2 31.5 65.4 29.1
-12.6 -13.0 84.6 36.4 79.8 34.0 75.0 31.7 72.6 30.5 70.2 29.4 65.4 27.2
-10.5 -11.0 84.6 34.0 79.8 31.8 75.0 29.7 72.6 28.6 70.2 27.6 65.4 25.6
-9.5-10.084.633.079.830.975.028.872.627.870.226.865.424.8
-8.5 -9.1 84.6 32.1 79.8 30.0 75.0 28.0 72.6 27.1 70.2 26.1 65.4 24.2
-7.0 -7.6 84.6 30.7 79.8 28.8 75.0 26.9 72.6 25.9 70.2 25.0 65.4 23.2
-5.0 -5.6 84.6 29.0 79.8 27.2 75.0 25.5 72.6 24.6 70.2 23.7 65.4 22.1
-3.0 -3.7 84.6 27.6 79.8 25.9 75.0 24.3 72.6 23.5 70.2 22.7 65.4 21.1
0.0 -0.784.625.779.824.175.022.672.621.970.221.165.419.7
3.0 2.2 84.6 24.1 79.8 22.7 75.0 21.3 72.6 20.6 70.2 19.9 65.4 18.5
5.0 4.1 84.6 23.1 79.8 21.8 75.0 20.5 72.6 19.8 70.2 19.1 65.4 17.9
7.0 6.0 84.6 22.3 79.8 21.0 75.0 19.7 72.6 19.1 70.2 18.5 65.4 17.2
9.0 7.9 84.6 21.5 79.8 20.3 75.0 19.0 72.6 18.4 70.2 17.9 65.4 16.7
11.0 9.8 84.620.879.819.675.018.472.617.870.217.365.416.2
13.0 11.8 84.6 20.1 79.8 18.9 75.0 17.8 72.6 17.3 70.2 16.7 65.4 15.6
15.0 13.7 84.6 19.4 79.8 18.3 75.0 17.3 72.6 16.7 70.2 16.2 65.4 15.2
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
