Daikin RXYQ22M7W1B [137/182] Capacity tables
![Daikin RXYQ22M7W1B [137/182] Capacity tables](/views2/1707499/page137/bg89.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
136
3 Capacity tables
3-2 Heating capacity
3-2-17 38HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 475
-19.8 -20.0 60.9 33.4 60.8 34.1 59.5 33.7 57.6 32.4 55.7 31.1 51.9 28.7
-18.8 -19.0 63.2 33.8 63.1 34.5 59.5 32.2 57.6 31.0 55.7 29.8 51.9 27.5
-16.7 -17.0 67.1 34.2 63.3 31.9 59.5 29.7 57.6 28.6 55.7 27.5 51.9 25.4
-14.7 -15.0 67.1 31.7 63.3 29.6 59.5 27.5 57.6 26.5 55.7 25.5 51.9 23.6
-12.6 -13.0 67.1 29.5 63.3 27.6 59.5 25.7 57.6 24.8 55.7 23.8 51.9 22.1
-10.5 -11.0 67.1 27.6 63.3 25.8 59.5 24.1 57.6 23.2 55.7 22.4 51.9 20.7
-9.5-10.067.126.763.325.059.523.357.622.555.721.751.920.1
-8.5 -9.1 67.1 26.0 63.3 24.3 59.5 22.7 57.6 21.9 55.7 21.2 51.9 19.6
-7.0 -7.6 67.1 24.9 63.3 23.3 59.5 21.8 57.6 21.0 55.7 20.3 51.9 18.8
-5.0 -5.6 67.1 23.5 63.3 22.1 59.5 20.6 57.6 19.9 55.7 19.3 51.9 17.9
-3.0 -3.7 67.1 22.4 63.3 21.0 59.5 19.7 57.6 19.0 55.7 18.4 51.9 17.1
0.0 -0.767.120.863.319.659.518.357.617.755.717.151.916.0
3.0 2.2 67.1 19.5 63.3 18.4 59.5 17.2 57.6 16.7 55.7 16.1 51.9 15.0
5.0 4.1 67.1 18.8 63.3 17.7 59.5 16.6 57.6 16.1 55.7 15.5 51.9 14.5
7.0 6.0 67.1 18.1 63.3 17.0 59.5 16.0 57.6 15.5 55.7 15.0 51.9 14.0
9.0 7.9 67.1 17.4 63.3 16.4 59.5 15.4 57.6 15.0 55.7 14.5 51.9 13.5
11.0 9.8 67.116.863.315.959.514.957.614.555.714.051.913.1
13.0 11.8 67.1 16.3 63.3 15.3 59.5 14.4 57.6 14.0 55.7 13.6 51.9 12.7
15.0 13.7 67.1 15.7 63.3 14.9 59.5 14.0 57.6 13.6 55.7 13.2 51.9 12.3
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
