Daikin RXYQ22M7W1B [60/182] Capacity tables
![Daikin RXYQ22M7W1B [60/182] Capacity tables](/views2/1707499/page60/bg3c.png)
18
3
• Systems • Outdoor Units
59
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-14 32HP
32HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 1,040 10 78.1 14.4 93.1 17.6 108 20.9 116 21.4 118 20.9 121 20.1 124 19.2
12 78.1 14.7 93.1 17.9 108 21.3 115 21.3 117 20.8 119 19.9 122 19.6
14 78.1 14.9 93.1 18.3 108 21.6 114 21.2 115 20.7 118 20.5 121 20.7
16 78.1 15.2 93.1 18.6 108 21.5 112 21.3 113 21.4 116 21.7 119 21.9
18 78.1 15.5 93.1 19.0 108 22.3 111 22.4 112 22.5 115 22.8 118 23.0
20 78.1 15.8 93.1 20.2 108 23.4 109 23.5 110 23.6 113 23.9 116 24.1
21 78.1 16.3 93.1 21.0 107 24.0 108 24.1 110 24.2 112 24.4 115 24.7
23 78.1 17.4 93.1 22.5 105 25.1 107 25.2 108 25.3 111 25.6 114 25.8
25 78.1 18.6 93.1 24.1 104 26.1 105 26.3 107 26.4 109 26.7 112 27.0
27 78.1 19.9 93.1 25.8 102 27.2 104 27.4 105 27.5 108 27.8 111 28.1
29 78.1 21.2 93.1 27.5 101 28.4 102 28.5 104 28.7 106 29.0 109 29.3
31 78.1 22.6 93.1 29.1 99.2 29.5 101 29.6 102 29.8 105 30.1 108 30.4
33 78.1 24.1 93.1 30.2 97.7 30.6 99.1 30.7 101 30.9 103 31.3 106 31.6
35 78.1 25.7 93.1 31.3 96.2 31.7 97.6 31.9 99.0 32.1 101 32.4 102 32.8
37 78.1 27.4 89.4 32.4 90.9 32.8 91.7 33.0 92.5 33.2 94.0 33.6 95.5 34.0
39 78.1 29.1 82.6 33.6 84.1 34.0 84.8 34.2 85.6 34.4 87.1 34.8 88.6 35.2
120 960 10 72.1 13.1 86.0 16.1 99.9 19.1 107 20.6 114 21.5 119 20.7 121 19.9
12 72.1 13.4 86.0 16.4 99.9 19.5 107 21.0 114 21.4 117 20.6 120 19.7
14 72.1 13.6 86.0 16.7 99.9 19.8 107 21.4 113 21.3 116 20.4 118 20.6
16 72.1 13.9 86.0 17.0 99.9 20.2 107 21.6 112 21.3 114 21.5 117 21.7
18 72.1 14.2 86.0 17.3 99.9 20.9 107 22.3 110 22.4 113 22.6 115 22.8
20 72.1 14.4 86.0 18.0 99.9 22.5 107 23.4 109 23.5 111 23.7 114 23.9
21 72.1 14.6 86.0 18.7 99.9 23.3 107 23.9 108 24.0 110 24.3 113 24.5
23 72.1 15.6 86.0 20.0 99.9 24.9 105 25.0 106 25.1 109 25.4 112 25.6
25 72.1 16.6 86.0 21.4 99.9 26.0 104 26.1 105 26.2 107 26.5 110 26.7
27 72.1 17.8 86.0 22.9 99.9 27.1 102 27.2 103 27.4 106 27.6 109 27.9
29 72.1 18.9 86.0 24.4 99.2 28.2 101 28.3 102 28.5 104 28.7 107 29.0
31 72.1 20.2 86.0 26.1 97.7 29.3 99.0 29.4 100 29.6 103 29.9 105 30.2
33 72.1 21.5 86.0 27.8 96.2 30.4 97.5 30.5 98.8 30.7 101 31.0 104 31.3
35 72.1 22.9 86.0 29.6 94.6 31.5 95.9 31.7 97.2 31.8 99.8 32.2 102 32.5
37 72.1 24.4 86.0 31.6 90.9 32.6 91.7 32.8 92.5 33.0 94.0 33.3 95.5 33.7
39 72.1 25.9 82.6 33.4 84.1 33.7 84.8 33.9 85.6 34.1 87.1 34.5 88.6 34.8
110 880 10 66.1 11.9 78.8 14.5 91.5 17.3 97.9 18.7 104 20.1 117 21.3 119 20.6
12 66.1 12.1 78.8 14.8 91.5 17.6 97.9 19.0 104 20.4 115 21.2 118 20.4
14 66.1 12.4 78.8 15.1 91.5 17.9 97.9 19.4 104 20.8 114 21.1 116 20.4
16 66.1 12.6 78.8 15.4 91.5 18.3 97.9 19.8 104 21.2 112 21.4 115 21.5
18 66.1 12.8 78.8 15.7 91.5 18.6 97.9 20.3 104 22.3 111 22.5 113 22.6
20 66.1 13.1 78.8 16.0 91.5 19.7 97.9 21.8 104 23.4 109 23.6 112 23.7
21 66.1 13.2 78.8 16.5 91.5 20.4 97.9 22.6 104 23.9 108 24.1 111 24.3
23 66.1 13.8 78.8 17.6 91.5 21.9 97.9 24.2 104 25.0 107 25.2 109 25.4
25 66.1 14.8 78.8 18.9 91.5 23.5 97.9 26.0 103 26.1 105 26.3 108 26.5
27 66.1 15.8 78.8 20.2 91.5 25.1 97.9 27.1 102 27.2 104 27.4 106 27.7
29 66.1 16.8 78.8 21.5 91.5 26.8 97.9 28.1 100 28.3 102 28.5 105 28.8
31 66.1 17.9 78.8 22.9 91.5 28.6 97.3 29.2 98.5 29.4 101 29.7 103 29.9
33 66.1 19.0 78.8 24.5 91.5 30.2 95.8 30.3 97.0 30.5 99.4 30.8 102 31.1
35 66.1 20.3 78.8 26.1 91.5 31.3 94.3 31.5 95.5 31.6 97.9 31.9 100 32.2
37 66.1 21.5 78.8 27.7 90.9 32.4 91.7 32.6 92.5 32.7 94.0 33.0 95.5 33.4
39 66.1 22.9 78.8 29.5 84.1 33.5 84.8 33.7 85.6 33.9 87.1 34.2 88.6 34.5
100 800 10 60.1 10.8 71.6 13.1 83.2 15.5 89.0 16.7 94.8 18.0 106 20.5 117 21.3
12 60.1 11.0 71.6 13.3 83.2 15.8 89.0 17.0 94.8 18.3 106 20.9 116 21.1
14 60.1 11.1 71.6 13.5 83.2 16.1 89.0 17.3 94.8 18.7 106 21.3 114 21.0
16 60.1 11.4 71.6 13.8 83.2 16.4 89.0 17.7 94.8 19.0 106 21.6 112 21.4
18 60.1 11.6 71.6 14.1 83.2 16.7 89.0 18.0 94.8 19.4 106 22.3 111 22.5
20 60.1 11.8 71.6 14.3 83.2 17.2 89.0 18.9 94.8 20.8 106 23.4 109 23.6
21 60.1 11.9 71.6 14.5 83.2 17.8 89.0 19.6 94.8 21.5 106 23.9 109 24.1
23 60.1 12.2 71.6 15.4 83.2 19.1 89.0 21.0 94.8 23.1 105 25.0 107 25.2
25 60.1 13.0 71.6 16.5 83.2 20.4 89.0 22.5 94.8 24.7 103 26.1 106 26.3
27 60.1 13.9 71.6 17.6 83.2 21.8 89.0 24.1 94.8 26.5 102 27.2 104 27.4
29 60.1 14.8 71.6 18.8 83.2 23.3 89.0 25.7 94.8 28.1 100 28.3 103 28.6
31 60.1 15.7 71.6 20.0 83.2 24.8 89.0 27.5 94.8 29.2 98.9 29.4 101 29.7
33 60.1 16.7 71.6 21.3 83.2 26.5 89.0 29.3 94.8 30.3 97.4 30.5 99.6 30.8
35 60.1 17.8 71.6 22.7 83.2 28.2 89.0 31.2 93.7 31.4 95.9 31.7 98.0 31.9
37 60.1 18.9 71.6 24.2 83.2 30.1 89.0 32.3 92.2 32.5 94.0 32.8 95.5 33.1
39 60.1 20.1 71.6 25.7 83.2 32.0 84.8 33.4 85.6 33.6 87.1 33.9 88.6 34.2
