Daikin RXYQ22M7W1B [69/182] Capacity tables
![Daikin RXYQ22M7W1B [69/182] Capacity tables](/views2/1707499/page69/bg45.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
68
3 Capacity tables
3-1 Cooling capacity
3-1-17 38HP
38HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 1,235 10 93.0 16.2 111 19.8 129 23.6 138 24.1 141 23.6 144 22.6 147 21.6
12 93.0 16.5 111 20.2 129 24.0 137 24.0 139 23.5 142 22.4 145 22.1
14 93.0 16.8 111 20.6 129 24.3 135 23.8 137 23.3 140 23.1 144 23.3
16 93.0 17.1 111 21.0 129 24.2 133 24.0 135 24.1 138 24.4 142 24.6
18 93.0 17.5 111 21.4 129 25.1 132 25.3 133 25.4 137 25.6 140 25.9
20 93.0 17.8 111 22.8 128 26.4 130 26.5 132 26.6 135 26.9 138 27.1
21 93.0 18.3 111 23.6 127 27.0 129 27.1 131 27.2 134 27.5 137 27.8
23 93.0 19.6 111 25.3 125 28.2 127 28.3 129 28.5 132 28.8 136 29.1
25 93.0 21.0 111 27.1 124 29.4 125 29.6 127 29.7 130 30.0 134 30.4
27 93.0 22.4 111 29.0 122 30.7 124 30.8 125 31.0 129 31.3 132 31.6
29 93.0 23.9 111 31.0 120 31.9 122 32.1 123 32.3 127 32.6 130 32.9
31 93.0 25.5 111 32.8 118 33.2 120 33.4 122 33.5 125 33.9 128 34.3
33 93.0 27.2 111 34.0 116 34.4 118 34.6 120 34.8 123 35.2 126 35.6
35 93.0 28.9 111 35.3 115 35.7 116 35.9 118 36.1 121 36.5 125 36.9
37 93.0 30.8 109 36.5 113 37.0 114 37.2 116 37.4 119 37.8 121 38.2
39 93.0 32.8 105 37.8 107 38.2 108 38.4 109 38.7 111 39.1 113 39.6
120 1,140 10 85.8 14.8 102 18.1 119 21.5 127 23.2 135 24.2 142 23.3 145 22.4
12 85.8 15.1 102 18.4 119 21.9 127 23.7 135 24.1 140 23.2 143 22.2
14 85.8 15.3 102 18.8 119 22.3 127 24.1 135 24.0 138 23.0 141 23.2
16 85.8 15.6 102 19.1 119 22.8 127 24.3 133 24.0 136 24.2 139 24.4
18 85.8 15.9 102 19.5 119 23.5 127 25.1 131 25.2 134 25.5 137 25.7
20 85.8 16.3 102 20.3 119 25.3 127 26.3 129 26.5 132 26.7 136 26.9
21 85.8 16.4 102 21.0 119 26.2 127 26.9 128 27.1 132 27.3 135 27.6
23 85.8 17.5 102 22.5 119 28.0 125 28.2 127 28.3 130 28.6 133 28.8
25 85.8 18.7 102 24.1 119 29.3 123 29.4 125 29.6 128 29.8 131 30.1
27 85.8 20.0 102 25.7 119 30.5 122 30.6 123 30.8 126 31.1 129 31.4
29 85.8 21.3 102 27.5 118 31.7 120 31.9 121 32.0 124 32.4 127 32.7
31 85.8 22.7 102 29.4 116 33.0 118 33.1 119 33.3 123 33.6 126 34.0
33 85.8 24.2 102 31.3 115 34.2 116 34.4 118 34.6 121 34.9 124 35.3
35 85.8 25.8 102 33.4 113 35.5 114 35.6 116 35.8 119 36.2 122 36.6
37 85.8 27.4 102 35.6 111 36.7 112 36.9 114 37.1 117 37.5 120 37.9
39 85.8 29.2 102 37.6 107 38.0 108 38.2 109 38.4 111 38.8 113 39.2
110 1,045 10 78.7 13.4 93.9 16.4 109 19.4 117 21.0 124 22.6 139 24.0 142 23.2
12 78.7 13.7 93.9 16.7 109 19.8 117 21.4 124 23.0 137 23.9 140 23.0
14 78.7 13.9 93.9 17.0 109 20.2 117 21.8 124 23.5 136 23.7 138 23.0
16 78.7 14.2 93.9 17.3 109 20.6 117 22.2 124 23.9 134 24.1 137 24.2
18 78.7 14.5 93.9 17.6 109 21.0 117 22.8 124 25.1 132 25.3 135 25.5
20 78.7 14.7 93.9 18.0 109 22.2 117 24.6 124 26.3 130 26.5 133 26.7
21 78.7 14.9 93.9 18.5 109 23.0 117 25.4 124 26.9 129 27.1 132 27.4
23 78.7 15.6 93.9 19.9 109 24.7 117 27.3 124 28.1 127 28.4 130 28.6
25 78.7 16.6 93.9 21.2 109 26.4 117 29.2 123 29.4 126 29.6 128 29.9
27 78.7 17.7 93.9 22.7 109 28.3 117 30.5 121 30.6 124 30.9 127 31.1
29 78.7 18.9 93.9 24.2 109 30.2 117 31.7 119 31.8 122 32.1 125 32.4
31 78.7 20.1 93.9 25.8 109 32.2 116 32.9 117 33.1 120 33.4 123 33.7
33 78.7 21.4 93.9 27.5 109 34.0 114 34.2 116 34.3 118 34.6 121 35.0
35 78.7 22.8 93.9 29.3 109 35.2 112 35.4 114 35.6 117 35.9 119 36.3
37 78.7 24.3 93.9 31.2 109 36.5 110 36.7 112 36.8 115 37.2 118 37.6
39 78.7 25.8 93.9 33.3 107 37.7 108 37.9 109 38.1 111 38.5 113 38.9
100 950 10 71.5 12.1 85.3 14.7 99.1 17.4 106 18.8 113 20.2 127 23.1 139 23.9
12 71.5 12.3 85.3 15.0 99.1 17.7 106 19.2 113 20.6 127 23.6 138 23.8
14 71.5 12.6 85.3 15.2 99.1 18.1 106 19.5 113 21.0 127 24.0 136 23.7
16 71.5 12.8 85.3 15.5 99.1 18.4 106 19.9 113 21.4 127 24.3 134 24.1
18 71.5 13.0 85.3 15.8 99.1 18.8 106 20.3 113 21.8 127 25.1 132 25.3
20 71.5 13.3 85.3 16.1 99.1 19.4 106 21.3 113 23.4 127 26.3 130 26.5
21 71.5 13.4 85.3 16.3 99.1 20.0 106 22.1 113 24.2 127 26.9 129 27.1
23 71.5 13.7 85.3 17.4 99.1 21.5 106 23.7 113 26.0 125 28.2 128 28.4
25 71.5 14.7 85.3 18.6 99.1 23.0 106 25.3 113 27.8 123 29.4 126 29.6
27 71.5 15.6 85.3 19.8 99.1 24.5 106 27.1 113 29.8 121 30.6 124 30.9
29 71.5 16.6 85.3 21.2 99.1 26.2 106 29.0 113 31.6 120 31.9 122 32.1
31 71.5 17.7 85.3 22.5 99.1 28.0 106 30.9 113 32.8 118 33.1 120 33.4
33 71.5 18.8 85.3 24.0 99.1 29.8 106 33.0 113 34.1 116 34.4 119 34.7
35 71.5 20.0 85.3 25.6 99.1 31.8 106 35.2 112 35.3 114 35.6 117 35.9
37 71.5 21.3 85.3 27.2 99.1 33.9 106 36.4 110 36.6 112 36.9 115 37.2
39 71.5 22.6 85.3 28.9 99.1 36.1 106 37.7 108 37.8 111 38.2 113 38.5
